Aluminum LED Garden Light Housing
Model No：EK-GLH-01
Match Power：40W/60W/80W
Contain Accessories：Aluminum Housing,Toughened Glass, Assembly Screws,Lamp Post pole,
Item: IP65 LED Street Lighting Housing
Power: 40W / 80W
Input Voltage: AC220 - 240V, 50/60 HZ
Color Choose: Dark Gray, Light Gray, Black, Customized etc
Lifespan: ≥50000 Hours
Product Features
- Aluminum housing 5years warranty
- Modular design for easy installation, replacement and maintenance
- Power choose : 40w-80w
- IP65 waterproof ADC12 Aluminum case
- IK09 certificates 4mm thickness tempering glass , 97% light transmittance
- 304 stainless steel screws protect your lighting lifetime
- Smooth body would greatly diminish dust accumulation and bird droppings heap up.
- Hidden driver box design, pretty type
- Lamp post lamp inner diameter 50mm/60mm
- Buckle for fixing heat sink could be opened without tools
- Standard colors : Dark gray, Light gray & Black or any special can be customized.
Product Specification
Outdoor Lighting 60W 80W Led Garden Light Housing
EK-GLH-01
IP65/IP66 , IK08/IK09,
Material : ADC12 Aluminum
Color Of Housing : Gray, Black,
Industry 80W Die Casting Aluminum Led Garden Light Housing
led street light housing 40w-80w, led street light fixture, High Efficient Aluminium LED Street Light Housing IP66 IK08
Outdoor led garden light fixture.
Whole Series & Specification
| Model Code | Housing Size （Mm) | Match Power | Lamp Post （Mm) | Weight （Kg) | Accessories |
| EK-GLH-01 | D479*H523 | 60W-120W | 60/80 | 6.5 | Heat sink body, PCB,LENS , Waterproof Rubber Ring，304 S/S screws, |
| Legend: Std = IP65 IK08 Testing certificates | |||||
| Housing Material ：Die-cast Aluminum + Armoured Glass | |||||
| Work temperature -40℃~50℃ 20%~90% H.R | |||||
