Aluminum LED Garden Light Housing

Model No:EK-GLH-01
Match Power:40W/60W/80W
Contain Accessories:Aluminum Housing,Toughened Glass, Assembly Screws,Lamp Post pole,
Item: IP65 LED Street Lighting Housing
Power: 40W / 80W
Input Voltage: AC220 - 240V, 50/60 HZ
Color Choose: Dark Gray, Light Gray, Black, Customized etc
Lifespan: ≥50000 Hours

Product Features

  1. Aluminum housing 5years warranty
  2. Modular design for easy installation, replacement and maintenance
  3. Power choose : 40w-80w
  4. IP65 waterproof ADC12 Aluminum case
  5. IK09 certificates 4mm thickness tempering glass , 97% light transmittance
  6. 304 stainless steel screws protect your lighting lifetime
  7. Smooth body would greatly diminish dust accumulation and bird droppings heap up.
  8. Hidden driver box design, pretty type
  9. Lamp post lamp inner diameter 50mm/60mm
  10. Buckle for fixing heat sink could be opened without tools
  11. Standard colors : Dark gray, Light gray & Black or any special can be customized.

Product Specification

Outdoor Lighting 60W 80W Led Garden Light Housing
IP65/IP66 , IK08/IK09,
Material : ADC12 Aluminum
Color Of Housing : Gray, Black,
Industry 80W Die Casting Aluminum Led Garden Light Housing
led street light housing 40w-80w, led street light fixture, High Efficient Aluminium LED Street Light Housing IP66 IK08
Outdoor led garden light fixture.

Whole Series & Specification

Model CodeHousing Size (Mm)Match PowerLamp Post (Mm)  Weight     (Kg)Accessories
EK-GLH-01D479*H52360W-120W60/806.5Heat sink body, PCB,LENS , Waterproof Rubber Ring,304 S/S screws,
Legend: Std = IP65 IK08 Testing certificates
Housing Material  :Die-cast  Aluminum  +  Armoured Glass
Work temperature -40℃~50℃ 20%~90% H.R
